Roblox Cache: RBXH, SQLite, and Offline Extraction

• Reverse Engineering

RobloxPlayer maintains a two‑layer cache on macOS: a SQLite index at ~/Library/Roblox/rbx-storage.db and a payload store under $TMPDIR/Roblox/rbx-storage. In a local snapshot, the index contained 96,104 rows totaling ~3.69 GiB. Each payload file begins with an RBXH wrapper that stores the source CDN URL and a byte payload. The payloads are often valid assets but may include a small prefix before the real file header, so trimming to the first magic bytes is sometimes required.

SQLite schema and what it means

The schema is small and readable. To inspect it directly:

sqlite3 ~/Library/Roblox/rbx-storage.db ".schema"
sqlite3 ~/Library/Roblox/rbx-storage.db "PRAGMA table_info(files);"

The files table includes:

  • id (BLOB): 16-byte key that becomes the filename (hex-encoded).
  • content (BLOB): small payloads are inlined here.
  • size: payload size in bytes.
  • hits: usage counter.
  • atime: access time in epoch milliseconds.
  • ttl: expiry in epoch seconds (0 means no TTL).

Large payloads tend to have content IS NULL and live on disk. The DB acts as the index.

Observations from the local snapshot:

  • The id is 16 bytes, matching the 32‑hex filenames on disk.
  • atime values are epoch milliseconds.
  • ttl values are epoch seconds; ttl = 0 appears frequently.
  • Most bytes were in category 10, and most ttl = 0 rows were in category 10.

Mapping DB IDs to files

The on-disk filename is just the hex version of the 16-byte ID. The first two hex chars are the shard folder. This makes the mapping deterministic: any DB row can be resolved to a single cache path without guessing.

What it’s for

This is a straightforward local cache: it reduces network fetches, speeds up asset loads, and lets the client re-use content across sessions. The DB is the index and metadata layer; the temp folder is the bulk storage. The CDN URL stored in the header is a handy provenance tag, not a guarantee the URL is publicly accessible.

How the cache gets populated

The cache is generated opportunistically during play. When a session joins a place, the client logs the place and universe, then immediately begins fetching assets that world references. Those asset requests are what land in rbx-storage and get indexed in rbx-storage.db.

On macOS, the join context is visible in ~/Library/Logs/Roblox/*_Player_*_last.log. A typical sequence shows a join with placeId, universeId, and server endpoint, followed by asset load lines. That temporal proximity is the practical link between a cache entry and a specific game session.

Example join context lines from the log:

! Joining game '472478ed-6c7b-4acc-a0ef-3605cc510ebc' place 120274717380291 at 10.186.5.23
GameJoinLoadTime ... placeid:120274717380291 ... universeid:9306827644 ...
Connecting to UDMUX server 128.116.48.33:62658, and RCC server 10.186.5.23:62658

RBXH: the cache wrapper

Every file I looked at starts with an RBXH header: a small wrapper that stores a version, the length of a URL, the URL itself, and then the payload. The version I saw was consistently 2. The URL is usually a rbxcdn.com host (sometimes with a tr.rbxcdn.com transform path). Visiting those URLs directly often returns “Access Denied” unless the request includes Roblox’s headers and auth, which is why the local cache is still useful for offline analysis.

Identifying payload types

A hex dump makes it obvious where the wrapper ends and the asset begins. In this sample, the RBXH header is followed by a KTX 2.0 texture (the KTX magic starts with AB 4B 54 58 20 and the KTX2 identifier 0D 0A 1A 0A follows):

xxd -g 1 -l 256 0093fd196e6523f1ac77c460fb972cd3

00000000: 52 42 58 48 02 00 00 00 36 00 00 00 68 74 74 70  RBXH....6...http
00000010: 73 3a 2f 2f 63 34 2e 72 62 78 63 64 6e 2e 63 6f  s://c4.rbxcdn.co
00000020: 6d 2f 36 64 30 66 64 62 32 36 39 30 66 34 38 64  m/6d0fdb2690f48d
00000030: 37 33 32 61 38 62 36 38 36 38 66 31 36 37 62 34  732a8b6868f167b4
00000040: 36 39 00 c8 00 00 00 00 00 00 00 00 00 00 00 9e  69..............
00000050: d2 11 00 95 84 de 67 03 00 00 00 ab 4b 54 58 20  ......g.....KTX
00000060: 32 30 bb 0d 0a 1a 0a 89 00 00 00 01 00 00 00 00  20..............
00000070: 04 00 00 00 04 00 00 00 00 00 00 00 00 00 00 01  ................
00000080: 00 00 00 0b 00 00 00 02 00 00 00 58 01 00 00 3c  ...........X...<
00000090: 00 00 00 94 01 00 00 88 01 00 00 00 00 00 00 00  ................
000000a0: 00 00 00 00 00 00 00 00 00 00 00 b5 88 04 00 00  ................
000000b0: 00 00 00 e9 49 0d 00 00 00 00 00 00 00 10 00 00  ....I...........
000000c0: 00 00 00 ae 2a 01 00 00 00 00 00 07 5e 03 00 00  ....*.......^...
000000d0: 00 00 00 00 00 04 00 00 00 00 00 09 4f 00 00 00  ............O...
000000e0: 00 00 00 a5 db 00 00 00 00 00 00 00 00 01 00 00  ................
000000f0: 00 00 00 36 17 00 00 00 00 00 00 d3 37 00 00 00  ...6........7...

What the payloads are

The payloads are the actual assets: images, audio, and various compressed or serialized blobs. In a small scan I saw PNG, WEBP, and OGG alongside zlib and gzip‑wrapped data. Some payloads are raw files. Others have a short prefix before the real file header.

Because the cache reflects assets already downloaded during play, you can extract locally cached images and audio for inspection without going back to the network.

White handshake icon extracted from Roblox cache
Handshake icon pulled from the local cache.
Gold trophy icon extracted from Roblox cache
Trophy icon pulled from the local cache.
Cached OGG pulled from disk for inspection. Use extracted audio only within licensing constraints.

Trimming the payload

Every file in the cache starts with the RBXH wrapper. After you skip that wrapper, some payloads begin immediately with the asset header, while others include a short prefix before the real header. I hit an OGG file that needed a 25‑byte trim before it would play. The fix is mechanical: scan for a magic header (like OggS or \x89PNG) and write from that offset. Once trimmed, QuickTime and Preview open the files normally. The same approach works for PNG and WEBP.

Repo

I packaged the scanning and extraction into a small repo:

→ github.com/storbeck/rbx-cache-scan

If you want more Roblox reverse engineering context, I also wrote: Tracing Roblox Purchase Prompt Functions.
